MDS60A0150-503-4-00 inverter

MDS60A0150-503-4-00 inverter

Product Details Introduction

1、 Core positioning

Brand and affiliation: Mitsubishi Electric MDS series high-end servo inverters, designed specifically for high-precision industrial motion control scenarios, featuring vector control technology and strong load adaptability

Core function: Convert three-phase AC power into adjustable voltage and frequency regulated electrical energy, accurately control the speed, torque, and position of servo motors, balance high-speed dynamic response and long-term operational stability, and adapt to medium and high-power precision equipment

Product status: Both brand new original and tested second-hand parts are available, and third-party channels have sufficient stock. Original products come with a one-year warranty and support professional installation and debugging guidance services

Related adaptation: Standard adaptation to Mitsubishi HC-SFS152 servo motor (1.5kW high inertia model), with optimal compatibility with Mitsubishi M70/M80 series CNC system

2、 Key parameters

Power supply and output:

Input specifications: three-phase AC 380-480V, frequency 50/60Hz ± 5%, allowable voltage fluctuation range ± 10%

Output performance: Rated output power of 15kW, rated output current of 30A (heavy load mode), maximum output frequency of 200Hz, supporting 0.3Hz low-frequency 150% torque output (closed-loop vector mode)

Control accuracy: Speed control accuracy ± 0.01% (closed-loop vector), frequency resolution 0.001Hz, position control accuracy ± 0.005 ° (dependent on encoder feedback)

Structure and Protection:

Physical specifications: Modular compact design, weighing approximately 12kg, compatible with Mitsubishi standard cabinet installation (cabinet depth ≥ 400mm)

Protection level: IP20 protection standard, to be installed in a dry, dust-free indoor computer room, avoiding contact with moisture and corrosive gases

Interface and Communication:

Control interface: Standard analog input (0-10V/4-20mA), 8-channel digital I/O terminals, supporting control functions such as forward/reverse/emergency stop/reset

Communication Protocol: Compatible with mainstream industrial buses such as Modbus RTU (compliant with industrial serial communication standards) and Profibus DP, supporting RS-485 communication interface (baud rate 9600-192000bps configurable)

Feedback support: Compatible with incremental/absolute value encoders (recommended 17 bit absolute value encoder), signal interface compatible with Mitsubishi servo motor standard feedback protocol

Expansion module: Optional Mitsubishi FR-A7NC communication module, expanding Ethernet communication function, realizing remote monitoring and parameter configuration

MDS60A0150-503-4-00 Product imag

MDS60A0150-503-4-00 ontroller Module

3BSC980006R361 Analog card
SCHNEIDE TCSESM043F2CS0 switches
SCHNEIDER TSXMRPC002M Analog features module
