IS220PDIAH1A independent module

IS220PDIAH1A independent module

Product Details Introduction

IS220PDIAH1A is a DIN rail mounted digital input module in the Mark VIe control system, used to collect dry contact or active/passive switch signals from industrial sites. This module supports multi-channel digital inputs, with each channel independently isolated and communicating with the main control system (such as controllers or I/O packs) through IONet.

Main technical parameters

Project Description

Module Type: Digital Input Module (PDI: Packaged Digital Input)

Number of input channels: 16 isolated digital input channels

The input voltage range is usually 24V DC (logic "1" is valid)

Channel insulation isolates each channel (between ground and other channels)

Channel status LED indicates that each channel has a corresponding indicator light displaying the on/off status

Communication interface IONet (supporting Ethernet and communication redundancy)

Installation method: DIN rail installation

The power supply is connected to the I/O Pack to provide low-voltage power (approximately 28V DC)

Compact module size structure, suitable for standard control cabinet space

Working temperature range -30 ° C to+65 ° C

Electrical safety and certification meet industrial safety standards such as CE, UL, CSA, ATEX (depending on version)

Product Features

16 isolated digital inputs: suitable for detecting status signals of dry contacts, relays, switches, etc

Module hot swappable: supports online replacement without power outage, reducing maintenance time

LED status indicator: convenient for on-site diagnosis and channel status viewing

Seamless integration with Mark VIe controller: compatible with all GE control network configurations

Built in signal protection: equipped with overvoltage, reverse connection, surge and other protection measures

Support redundant system architecture: can be applied in dual channel redundant architecture

Product imag
