MVI46-GEC Communication Interface Module

MVI46-GEC is a universal ASCII Ethernet communication module designed by ProSoft specifically for Rockwell SLC 500 series PLCs. It is used to connect SLC systems to TCP/IP networks and achieve transparent data exchange with various ASCII protocol devices.

Core Features

Single slot compatible with SLC 500 rack, both local and expansion racks can be installed

1 10/100Mbps RJ45 Ethernet port, communication based on TCP/IP protocol

Supports client/server dual-mode, can initiate or passively receive connections

Built in 5000 word register database for data exchange between PLC and ASCII devices

Independent communication processing, does not occupy SLC main processor resources, ensuring system real-time performance

Support custom ASCII message format and adapt to various non-standard ASCII devices

Provide RS-232 configuration port for local parameter configuration and status diagnosis

Industrial grade wide temperature design (0-60 ℃), strong anti-interference, suitable for harsh industrial sites

Seamless integration with RSLogix 500, direct access to module data through ladder logic

Supports multiple concurrent connections and can simultaneously interface with multiple ASCII devices

Provide configuration software and sample programs to simplify deployment and debugging

Support data forwarding and protocol conversion to achieve interconnectivity between different ASCII devices

Compatible with SLC 5/02 and above processors, suitable for upgrading old systems

Backboard current 800mA @ 5VDC, low-power design

Support fault diagnosis and status feedback for easy system maintenance

Typical Applications

SLC PLC is networked with ASCII devices such as barcode scanners and weighing instruments

Connect old ASCII protocol devices to achieve data collection and remote monitoring

Ethernet data transmission with printers, terminal devices, etc

Non standard equipment modification, achieving communication between PLC and ASCII devices through Ethernet

Multi site distributed system, implementing ASCII data sharing through TCP/IP network

Remote control of ASCII devices such as sensors and actuators in industrial sites

This module provides flexible and universal ASCII Ethernet communication capabilities for SLC systems, quickly connecting the network links between PLCs and various ASCII devices, meeting the networking and data exchange needs of non-standard equipment in industrial sites.

MVI46-GEC Product imag
