Hirschmann MM20-Z6Z6Z6Z6Z6SAHH Port Media Module

Hirschmann MM20-Z6Z6Z6Z6Z6SAHH Port Media Module

Product Details Introduction

Hirschmann MM20-Z6Z6Z6Z6Z6SAHH is a port media module in the Hirschmann MM20 series, designed specifically for network transmission needs in industrial communication and automation systems. This module provides flexible interface options to enable conversion between different media (such as fiber optic and copper cables), ensuring reliable data transmission in complex industrial environments. This module is commonly used in network environments that require high reliability and redundant protection.

This module is equipped with multiple Ethernet ports and can support various network connection forms, suitable for various industrial network applications. Whether it is switch expansion, media conversion, or redundant network design, this module can provide stable performance.

Main technical parameters

Project parameter description

Module Type Port Media Module

Fiber interface type: 6-way fiber interface (supporting multimode and single-mode fibers)

Copper cable interface type 6-way 10/100/1000 Mbps Ethernet port

Port speed supports 10/100/1000 Mbps adaptive

Network redundancy support supports redundant network protocols such as RSTP, PRP, Hirschmann specific industrial protocols

Power supply 24V DC (standard power input)

Working temperature range -40 ° C to+75 ° C

Installation method: DIN rail installation, compact design

Environmental adaptability: dustproof and waterproof (compliant with IP30 or higher protection level)

Certification standards IEC 61850-3, IEEE 802.3, UL, CE certification

LED status indicator provides port status, connection indication, and fault alarm light

Product Features

High flexibility port configuration: Provides up to 6 fiber optic and 6 copper cable interfaces to adapt to different network requirements and communication media

Supporting redundant networks: With powerful redundancy support capabilities, it ensures high availability of industrial networks and reduces downtime

High temperature stability: With a wide range of operating temperatures, it can operate stably in harsh environments and is suitable for both high and low temperature environments

Modular design: Modular design, easy to expand and maintain, supports different types of media conversion and network topology requirements

Intelligent Network Management: Supports multiple industrial network protocols for seamless integration with existing control systems and network devices

High durability: sturdy and durable, meeting the demanding requirements of industrial environments, with strong anti-interference ability and reliability

Easy to install: Supports standard DIN rail installation, simplifies on-site installation and deployment process

Product imag
