MVI46-DFCM is a DF1 master/slave serial communication module designed by ProSoft specifically for Rockwell SLC series PLCs. It is used to expand the DF1 communication capability of SLC systems and achieve stable data exchange with AB PLC, HMI, SCADA, and third-party DF1 devices.

Core Features

Single slot compatible with SLC 500 rack, plug and play, easy to install

Dual independent serial ports, supporting RS-232/RS-485 electrical interfaces

Each port can be independently configured as a DF1 master or slave, with half/full duplex options available

Built in 5000 word register database for data exchange between PLC and DF1 network

Asynchronous data transmission, does not occupy PLC main processor resources, ensures system real-time performance

Support DF1 full protocol functions: read/write, point-to-point/multipoint, broadcast communication

Configurable communication parameters (baud rate, parity, stop bit), suitable for multiple devices

Industrial grade wide temperature design, strong anti-interference ability, suitable for harsh industrial sites

Seamless integration with RSLogix 500, direct access to module data through ladder logic

Provide configuration software and sample programs to simplify debugging and deployment

Support fault diagnosis and status feedback for easy system maintenance

Can serve as a DF1 gateway to achieve transparent data forwarding between multiple devices

Compatible with SLC 5/02 and above processors, suitable for upgrading old systems

Low backplane current (800mA @ 5.1VDC) reduces system power consumption

Support remote configuration and online monitoring to improve operational efficiency

Typical Applications

DF1 networking communication between SLC PLC and AB PLC (such as PLC-5, ControlLogix)

Data acquisition and monitoring of HMI/SCADA system and SLC PLC in the factory

Third party DF1 devices such as power monitoring and intelligent instruments are connected to the SLC system

Renovation of old production lines and expansion of serial communication interfaces for SLC systems

Multi site distributed control system, data sharing achieved through DF1 bus

Remote control and data acquisition of industrial field equipment (frequency converters, sensors, RTUs)

This module efficiently extends the DF1 communication capability of SLC system, connecting PLC with various industrial equipment through stable and flexible serial links, meeting the core requirements of data exchange and remote monitoring in automation systems.
