3BHE014070R0101 Drive Control Board

3BHE014070R0101 Drive Control Board

Product Details Introduction

The ABB 3BHE014070R0101 drive control board is a key component in the ABB inverter system, specifically designed to control and regulate various parameters of the drive system. It is commonly used in ABB's high or medium voltage drive systems, responsible for controlling, signal processing, and protecting motors. This control board has the function of real-time monitoring of the operating status of motors and frequency converters, as well as executing control commands such as current, voltage, and frequency.

major function

Motor control: precise control of motor start, stop, speed adjustment, etc.

Inverter modulation: Drive the inverter module to achieve efficient energy conversion through PWM (pulse width modulation) control signals.

Fault diagnosis: With self diagnostic function, it can monitor key parameters such as voltage, current, temperature in real time and trigger alarms.

System protection: Provides protection functions such as current overload, over temperature, and short circuit.

Communication interface: Supports communication with ABB control systems or other external devices, including RS-485 or dedicated bus interfaces.

Signal sampling and processing: Real time acquisition and processing of voltage, current, and other signals to ensure precise control of the system.

application area

Industrial automation: used for various industrial automation equipment and drive control systems.

Electricity and Energy: Suitable for high-voltage motor drive control systems such as fans, pumps, compressors, etc.

Petrochemicals and Metallurgy: Widely used in high-pressure drive control.

Metallurgy, power, mining and other industries: can be used for motor control and drive management in these fields.

Typical hardware parameters

Power supply voltage: provided by the main control unit or power module (e.g. 5V, 15V).

Communication interface: Common interfaces include RS-485, CAN bus, etc.

Working temperature range: usually from 0 ° C to 60 ° C.

Storage temperature range: -40 ° C to 85 ° C.

Board structure: Multi layer circuit board, usually with protective coating to prevent environmental interference.
