TRICONEX RO3451 Controller Module

TRICONEX RO3451 Controller Module

Product Details Introduction

Model: TRICONEX RO3451

Type: Relay Output Module

product overview

TRICONEX RO3451 is a relay output module in the Tricon safety control system, used to transmit control signals to field devices through relay contacts. It is suitable for controlling load devices that require electrical isolation, such as contactors, indicator lights, alarms, relays, etc.

This module supports triple redundancy configuration and meets the high integrity requirements of Safety Instrumented Systems (SIS). It is one of the important safety output modules in the Tricon system.

Module functionality

Provide 32 independent relay output channels

Convert digital control signals into relay contact outputs

The output signal has electrical isolation to protect the stable operation of the system

Used for controlling and driving on-site equipment

Support redundant architecture synchronization work to improve system availability

technical specifications

Number of output channels: 32 relay outputs

Relay type: Form A Single pole Single throw (SPST-NO) dry contact output

Rated contact capacity:

Maximum voltage: 30 VDC/250 VAC

Maximum current: 2 A (resistive load)

Channel isolation: Each channel is electrically isolated from the system

Response time: within approximately 10 milliseconds

Output status display: The front panel has LED status indicators for each channel

Module redundancy: Three channel independent drive and voting output mechanism to ensure output reliability

Installation structure: Plug in module, used in conjunction with a dedicated base

Hot swappable support: Modules can be replaced online without the need for system power off

Product imag
