MVRL2100-4601 is a liquid cooled rectifier module produced by Converteam (now GE Energy), mainly used for the MV3000 DELTA drive system. The main function of this module is to convert AC power into unsmoothed DC power, providing reliable DC power support for medium voltage drive systems.

Main features:

Double six pulse rectifier design: Each module contains two three-phase six pulse rectifiers that can be independently connected to AC inputs, providing flexible configuration options.

Support 12 pulse network bridging: achieve a 30 ° phase shift through an external power transformer, and connect two DC positive outputs using an inter bridge transformer. It can be configured as a 12 pulse rectifier to reduce harmonic distortion.

Pre charging circuit: Built in pre charging circuit, which can charge the DC link capacitor of the transistor module through a current limiting resistor to ensure safe system startup.

Liquid cooling design: Adopting liquid cooling method to improve heat dissipation efficiency, suitable for high power density application scenarios.

Temperature monitoring: equipped with thermistor and temperature controller, real-time monitoring of module temperature, providing over temperature protection to ensure stable system operation.

Application areas:

Medium voltage drive system: widely used in the field of industrial automation, providing stable DC power supply for medium voltage motors and drive equipment.

Power transmission and distribution: In the power system, it is used to convert alternating current into direct current to meet the power supply needs of specific equipment.

Renewable energy: used in wind and hydroelectric power systems for rectification and energy conversion to improve energy utilization efficiency.

Technical specifications:

Maximum DC output voltage: 1250 VDC

Cooling method: liquid cooling

Installation method: Compatible with standard DELTA installation framework

Product imag
