NI PXIE-4147 Measurement Unit Module

NI PXIE-4147 Measurement Unit Module

Product Details Introduction

NI PXIe-4147 is a 4-channel precision PXI source measurement unit (SMU) developed by National Instruments (NI) in the United States, specifically designed for high pin count applications. This module has four quadrant operation function, and each channel integrates remote (4-wire) sensing to ensure accurate measurement.

Main features:

High channel density: A single module provides 4 independent SMU channels, suitable for applications that require multi-channel synchronous measurement.

Four quadrant operation: Each channel supports four quadrant operation, which can source and absorb current to meet various testing requirements.

High sampling rate: High sampling rate helps shorten measurement time, capture transient characteristics of the device, and achieve fast I-V characteristic analysis.

SourceAdapt technology: The response of PXIe-4147 to any load can be adjusted to achieve optimal stability and minimal transient characteristics.

Deterministic hardware sequence: Built in high-speed sequence engine, supporting synchronous operation between SMUs or with other instruments such as switches or high-speed digital testing modules.

Technical specifications:

Voltage range: ± 8 V

DC current range: ± 3 A

Current sensitivity: 100 fA

Maximum DC power: 24 W (source/absorption)

PXIe-4147 is suitable for semiconductor device testing, electronic component characteristic analysis, and other applications that require high-precision, multi-channel power supply and measurement. Its modular design makes it easy to integrate into existing PXI testing systems, providing flexible and efficient testing solutions.

Product imag
