Woodward 5501-412 Analog I/O Module

Woodward 5501-412 Analog I/O Module

Product Details Introduction

Woodward 5501-412 is an analog I/O module used in industrial control systems, mainly integrated into Woodward's controller platforms (such as MicroNet, 2301E, or Atlas series), responsible for the input and output interface functions of analog signals, suitable for precision control and process monitoring tasks.

1、 Product basic information:

Model: 5501-412

Type: Analog I/O module

Brand: Woodward

Compatible platform: Woodward control system (such as MicroNet or Atlas series)

2、 Main functions and features:

Analog input (AI) function:

Supports multiple channels of analog voltage or current signal input

Typical input range: 0-5V, 0-10V, 4-20 mA, etc. (depending on specific configuration)

Can be used to collect signals from sensors, transmitters, and other devices, such as process variables such as pressure, temperature, flow rate, etc

Analog Output (AO) Function:

Provide analog output control for multiple channels

Used to send control signals to actuators, frequency converters, analog instruments, etc

The output range is usually 0-5V, 0-10V, or 4-20mA (configurable)

Accuracy and stability:

High resolution A/D and D/A converters

Strong noise resistance, suitable for operation in harsh industrial environments

Provide isolation protection to prevent signal interference or equipment damage

Diagnosis and status monitoring:

Integrated self diagnostic function

Support status LED display of channel operation status and fault information

Online monitoring and configuration can be carried out through system software

Product imag
