Product Details Introduction

IC695CPE400-ABAB is a high-performance central processing unit (CPU) module in the PACSystems RX3i series control system produced by GE (General Electric, now Emerson). It integrates Ethernet ports for communication with a host computer, remote I/O, or other controllers.

Although the user mentioned the "Ethernet port module", in fact, IC695CPE400-ABAB is an advanced CPU module with built-in Ethernet functionality, which has dual functions of network communication and logic control.

1、 Basic Information

Brand: GE (General Electric)/Emerson

Series: PACSystems RX3i

Model: IC695CPE400-ABAB

Product type: Advanced Control Processor (CPU) module with Ethernet interface

Functional positioning: Logic control+Ethernet communication

2、 Main functions

Built in Ethernet port

Supports multiple protocols: Modbus TCP/IP, SRTP, Ethernet Global Data (EGD), OPC-UA, etc

Can be used for remote I/O communication, HMI/SCADA data transmission, inter controller synchronization, etc

Powerful processing capability

Dual core CPU, supporting high-speed logical operations

Suitable for large-scale applications and complex control processes

Good compatibility

Compatible with all I/O modules and communication modules in the RX3i series

Can serve as the main control unit for standard or redundant control systems

Support PAC Machine Edition software programming

Support programming languages such as Relay Ladder Diagram (RLD), Structured Text, Function Block, etc

Data storage capability

Large capacity memory, supporting local storage of user logic and data

Support external SD card expansion

Product imag
