PM864AK01 3BSE01816R1 Controller Module

PM864AK01 3BSE01816R1 Controller Module

Product Details Introduction

1、 Basic Product Information

Product model: PM864AK01

Order number: 3BSE018161R1

Manufacturer: ABB

Series: AC 800M Controller Series

2、 Function Description

PM864AK01 is a mid to high end processor module in the ABB AC 800M series, suitable for 800xA control systems, used to implement core logic operations, data communication, and process control tasks in distributed control systems (DCS).

3、 Technical specifications

Processor: Motorola PowerPC 604e, 400 MHz

Memory: 512 MB SDRAM, 256 MB Flash

Power requirement: 24V DC

Communication interface:

Ethernet (10/100 Mbps)

Serial port (RS-232/RS-485)

PROFIBUS DP (by connecting expansion modules)

USB (for configuration/maintenance)

Operating environment:

Working temperature: 0 ℃~+55 ℃

Storage temperature: -40 ℃~+70 ℃

Protection level: IP20 (installed in a suitable cabinet)

Installation method: DIN rail installation

4、 Module features

Modular design, supporting hot swappable replacement

Can be used in conjunction with AC 800M series I/O modules

Support redundant configuration to improve system reliability

Multiple communication protocols are supported, making it easy to integrate third-party devices

Compatible with ABB 800xA distributed control system

Product imag
