Product Details Introduction

Yokogawa WT1803E Precision Power Analyzer is a high-precision power measurement tool widely used in industrial and research and development fields, especially in electrical equipment, energy management systems, and various environments that require high-precision power and energy measurement. WT1803E provides very high measurement accuracy and functionality, suitable for various power systems ranging from single-phase to three-phase.

Main features:

High precision measurement:

0.1% basic accuracy, capable of providing high-precision power and electricity measurement, ensuring reliability under various testing conditions.

Capable of accurately measuring various voltage and current signals, suitable for complex application scenarios.

Wide measurement range:

Supports a wide range of voltage and current, suitable for testing power equipment from low power to high power.

The measurement voltage range is from 1 mV to 1000 V, and the current range is from 1 μ A to 30 A, meeting the needs of various electrical equipment.

Three phase power measurement:

Support power measurement for three-phase systems, capable of simultaneously measuring key parameters such as three-phase power, power factor, load, etc., suitable for power monitoring of industrial equipment.

High frequency response:

The frequency response capability of 2 MHz enables WT1803E to perform fast response measurements, making it particularly suitable for power measurement of high-frequency electronic products, inverters, and other frequency conversion equipment.

Data recording and analysis function:

Built in storage function, supporting long-term measurement data recording for easy analysis and post-processing.

Provide waveform and trend charts to enable users to intuitively analyze power quality and measurement data.

Comprehensive analysis of power quality:

In addition to basic power measurement, it also supports measurement of power quality such as harmonic analysis, energy analysis, power factor, frequency analysis, etc., to assist users in comprehensive power system monitoring.

Multiple displays and interfaces:

Provide color display and touch screen operation, allowing users to quickly set, adjust, and view measurement results.

Supports interfaces such as USB, LAN, GPIB, etc., facilitating data export, remote control, and integration with other devices.

Flexible measurement mode:

Supports multiple measurement modes, including instantaneous power, average power, maximum/minimum power, relative power, etc., suitable for different application scenarios.

Product imag
