R&S ZNB8 Vector Network Analyzer
- Goods status： new/used
- Delivery date: stock
- The quality assurance period： 365 days
- Phone/WhatsApp/WeChat：+86 15270269218
- Email：stodcdcs@gmail.com
- Tags：
- Get the latest price：Click to consult
R&S ZNB8 Vector Network Analyzer
Product Details Introduction
The R&S ZNB8 Vector Network Analyzer is a high-performance Vector Network Analyzer (VNA) produced by Rohde&Schwarz (R&S) in Germany. It is mainly used for radio frequency (RF) and microwave testing, and is suitable for measuring antennas, filters, amplifiers, RF circuits, passive/active devices, etc.
Main features of R&S ZNB8
1. Frequency range
9 kHz to 8 GHz (supports broadband measurement).
2. High precision&low noise
Dynamic range:> 140 dB (typical value, 10 Hz IF bandwidth).
Low trace noise:< 0.004 dB RMS (at an IF bandwidth of 10 kHz).
Low background noise:- 120 dBm, suitable for high-precision measurement.
3. Quickly measure speed
Fast speed: Measurement time only takes 4 ms (401 points), suitable for high-throughput production testing.
Support multi port measurement, capable of testing multiple RF channels simultaneously to improve efficiency.
4. Large touch screen&user-friendly interface
Equipped with a 12.1-inch high-resolution touch screen, the operation is intuitive.
Multi window display, supports user-defined layout, and can view multiple parameters simultaneously.
5. Multiple port configurations
2-port/4-port options are available, supporting differential measurement and suitable for different application requirements.
Low insertion loss, excellent source matching performance, suitable for high-precision measurement.
6. Powerful measurement function
S-parameter measurement (S11, S21, S12, S22), suitable for network analysis of filters, amplifiers, etc.
Time Domain Analysis (TDR) is suitable for high-speed signal integrity analysis, such as PCB routing, connectors, packaging, etc.
Harmonic measurement and intermodulation distortion (IMD) analysis, suitable for active device testing.
Pulse measurement can be used for applications such as radar and wireless communication.
7. Compatible with multiple interfaces
GPIB, USB, LAN (VXI-11), SCPI remote control, can be integrated into automated testing systems.
Supports programming with Python, LabVIEW, and MATLAB, making it convenient for engineers to develop testing plans
Product imag
