Product Details Introduction

MVI94-GSC Universal Serial Communication Module

MVI94-GSC is a universal ASCII serial communication module designed by ProSoft specifically for the Rockwell Flex I/O platform. It is used to connect various RS-232/422/485 serial devices to the Flex I/O system, achieving transparent data exchange.

1、 Core product features

Compatible with Flex I/O platform, single slot installation, supports local/remote rack deployment

1 independent configurable serial port (RS-232/422/485 optional), supporting full duplex/half duplex communication

Baud rate 110-115200bps, data bits 5-8, parity/stop bits customizable

Support flexible configuration of stream mode, termination character, timeout, packet size, etc

The maximum receiving cache is 4096 characters, and the maximum single transmission is 10 characters, meeting the data collection requirements

Asynchronous communication with Flex I/O processors without occupying the main scanning cycle

Provide standard ladder diagram examples and AOI to simplify PLC program integration

Independent CFG configuration port, supporting online debugging and parameter download

LED status indicator light for quick diagnosis of module, serial port, and communication status

Hardware electrical isolation enhances the anti-interference capability of industrial sites

Industrial grade wide temperature range (-40 ℃~70 ℃), anti vibration and anti impact design

Support multiple handshake methods such as RTS/CTS, XON/XOFF, etc

Can simulate terminal ports and interface with old-fashioned serial port terminals and HMI

Supports transparent data transmission and is compatible with various ASCII protocol devices

Suitable for the renovation of old equipment and data acquisition scenarios in Flex I/O systems

2、 Typical application areas

Discrete manufacturing: docking barcode scanners RFID、 Spray coding machine, labeling machine, weighing instrument, realize production data collection and traceability

Logistics warehousing: connecting electronic tag picking, AGV scheduling terminals, and three-dimensional warehouse equipment

Process industry: access to flow meters, pressure/level transmitters, water quality analyzers, valve controllers

Upgrading old equipment: Connecting RS-232/485 instruments, PLC, HMI to Flex I/O system

Universal data collection: As a serial gateway, it interfaces with non-standard ASCII devices, terminals, and printers

MVI94-GSC Product imag
