Product Details Introduction

FBM202 P0926EQ is a thermocouple input module in the Foxboro I/A Series series, which supports multiple types of thermocouple signals (including K, J, T, E, B, R, S, etc.) and can achieve high-precision temperature measurement function. The module is used in process control systems and is particularly suitable for temperature acquisition needs in thermal process monitoring, industrial automation, chemical and power industries.

Main technical parameters

Project parameter description

Input type: thermocouple input (K, J, T, E, B, R, S, N, etc.)

Number of input channels: 8 channels, isolated thermocouple input

Analog input range related to thermocouple type (automatically compensates for cold junction temperature)

Accuracy (typical) ± 0.1% reading ± 1 ° C (depending on thermocouple type)

Isolation feature: The channel is completely isolated between channels and between power sources and channels

Cold end compensation with built-in cold end temperature compensation (CJC)

Input signal update rate of 50 milliseconds (per channel)

Working temperature range: 0 ° C to 60 ° C (standard module)

Installation method: Install on the Foxboro FBM channel base plate

Communication method with I/A Series control system through module bus communication

The module power is supplied through the system backplane (24 VDC common bus)

Functional Features

Multiple thermocouple compatibility: Supports a wide range of thermocouple standard types to meet various industrial temperature measurement needs

Independent isolation of each channel: Electrical isolation between each input channel improves the system's anti-interference ability and safety

High precision measurement: Built in cold end compensation ensures thermocouple measurement accuracy

Modular design: Hot swappable modules, supporting quick on-site replacement and maintenance

Adaptation System: Fully compatible with Foxboro I/A Series control system, seamlessly integrated

Product imag
