PL810 3BDH000311R0101 power link module

PL810 3BDH000311R0101 power link module

Product Details Introduction

ABB PL810 (3BDH000311R0101) is a power link module used in ABB AC800M control system. Its main function is to provide stable power connection and distribution between I/O modules, and it is one of the essential components in module assembly.

1、 Basic Information

Product Model: PL810

Order number: 3BDH000311R0101

Module type: Power Link Module

System Platform: ABB AC800M Control System

Adaptation object: S800 I/O module series

Installation method: DIN rail installation

2、 Functional Features

Used to transfer power from one I/O module to adjacent modules

Realize stable 24V DC power connection between I/O groups

Reduce external wiring, improve installation efficiency and module compactness

The module itself has no electronic function and does not participate in data processing

Support redundant configuration to enhance system reliability

3、 Technical parameters

Working voltage: 24V DC (compatible with S800 I/O system)

Rated current: determined based on the total load demand of the system (usually a few amperes)

Environmental temperature range: -25 ℃ to+70 ℃

Installation position: located between two S800 modules, used for power "bridging"

Size: Small modular design, compatible with standard S800 size architecture

4、 Application Fields

Power Automation: Distribution and Power Plant DCS System

Chemical and Pharmaceutical: I/O Power Supply Links in Precision Control Systems

Water treatment engineering: module power distribution for pump stations and valve control units

Food and beverage, paper industry: modular power supply in process control systems

Metallurgy and Machinery Manufacturing: IO Expansion Unit Power Connection in Large Equipment Automation
