MVI71-DFNT Ethernet Communication Module

MVI71-DFNT Ethernet Communication Module

Product Details Introduction

MVI71-DFNT is an EtherNet/IP communication module designed by ProSoft specifically for Rockwell PLC-5 (1771 rack), which enables transparent interconnection between PLC-5 and EtherNet/IP network devices. It also supports DF1 over Ethernet and remote programming. The following are the core application areas:

1、 Discrete manufacturing industry

Automobile whole vehicle and component production line: docking robots, welding equipment, glue workstation, torque detection equipment, to achieve production cycle coordination and data traceability.

Electronic assembly and SMT production line: Connect AOI optical inspection machine, SPI solder paste inspection equipment, labeling machine, material error prevention system, and complete real-time uploading of quality data.

Packaging and food processing: Integrate weighing and ingredient systems, film packaging machines, packing machines, and conveyor control systems to achieve formula management and batch traceability.

Mechanical machining center: connects CNC milling machines/lathes, tool monitoring equipment, and online measuring instruments to achieve machining data collection and equipment networking.

2、 Process Industry (Process Industry)

Oil and gas: Connect wellhead RTUs, metering levers, flow meters, pressure/temperature transmitters to achieve remote monitoring and data acquisition of oil and gas fields.

Power industry: Connect relay protection devices, measurement and control terminals, energy meters, and ring main units to meet the monitoring and remote control needs of substations.

Chemical and Pharmaceutical: Connected to DCS system, pH/ORP meter, liquid level meter, and reactor control system to achieve real-time monitoring and linkage control of process parameters.

Water treatment and environmental protection: Integrate water quality online analyzers, dosing pumps, pumping stations, and sludge dewatering equipment to achieve automated operation of water plants/sewage treatment plants.

Metallurgy and Building Materials: Connect furnace temperature control systems, rolling mill instruments, raw material weighing equipment, and kiln controllers to ensure continuous and stable production.

3、 Logistics and Warehouse Automation

Intelligent three-dimensional warehouse: docking with stacker cranes, AGV carts, three-dimensional shelf control systems, and scanning recognition equipment to achieve efficient warehousing operations.

Port and Terminal: Connect shore bridges, yard bridges, belt scales, and container terminal equipment to complete real-time collection and transmission of loading and unloading data.

4、 Infrastructure and Special Scenarios

Rail transit: Integrate station signal systems, turnstiles, passenger information display terminals, and environmental monitoring equipment to ensure the safe operation of stations.

Intelligent Building: Connecting building automation systems, elevator monitoring, energy consumption meters, and security equipment to achieve intelligent management of buildings.

Upgrading and renovating old equipment: Connect legacy PLC-5 devices to EtherNet/IP networks to achieve system upgrades and data sharing, reducing renovation costs.

Remote monitoring and maintenance: Through the transparent transmission channel of the module, remote PLC program download, debugging, and fault diagnosis can be achieved to improve maintenance efficiency.

MVI71-DFNT Product imag
