Product Details Introduction

Product Features of Xycom XVME-661 Processor Module

Xycom XVME-661 is a low-power Pentium III architecture 6U VMEbus high-performance PC compatible processor module, featuring low power consumption, high integration, strong scalability, and industrial stability, suitable for embedded control scenarios with strict energy consumption and reliability requirements.

Equipped with a low-power Intel Pentium III 700MHz processor and built-in 256KB full speed on-chip L2 cache, it balances high performance and low power consumption.

Supports up to 256MB SDRAM (single 144 pin SODIMM) to meet the requirements of complex programs and multitasking.

Integrated 64 bit AGP graphics controller, equipped with 4MB independent video memory, supporting local graphics display output.

Provide dual 10/100Mbps Ethernet controllers with RJ-45 Ethernet ports on the front panel, allowing for high-speed network communication without the need for expansion.

Built in 32-bit electrically isolated PMC expansion slot, which can flexibly expand high-speed I/O, communication, and dedicated functional modules.

Equipped with Type I/II IDE+CompactFlash slots, it supports solid-state and mechanical storage, making diskless booting more reliable.

Integrated PCI EIDE and floppy drive controller, capable of driving dual EIDE devices and single floppy drives, compatible with traditional storage peripherals.

Provide 2 high-speed RS-232 serial ports, 1 EPP/ECP parallel port, USB, PS/2 keyboard and mouse interfaces, with comprehensive basic I/O.

Supports VME64 bus protocol, compatible with A32/A24/A16: D64/D32/D16 master/slave modes, efficient data transmission.

Adopting a 6U VME dual slot board structure, it has high mechanical strength and is compatible with standard industrial VME racks.

Industrial grade design, working temperature range of 0 ℃~+55 ℃, storage range of -40 ℃~+70 ℃, anti electromagnetic interference, long-term stability.

Built in hardware watchdog and real-time clock (RTC, with battery backup) to ensure system abnormal reset and time synchronization.

The front panel integrates status LEDs, which display real-time CPU, bus, and network status for easy on-site debugging and diagnosis.

Compatible with breakout modules such as XVME-973/974/977, expandable with more I/O interfaces, and flexible configuration.

Suitable for low-power and high-performance scenarios such as industrial automation, embedded control, data acquisition, testing and measurement, military/aviation electronics, etc.

XVME-661 Product imag

XVME-661 ontroller Module
