Xycom XVME-660 processor module

Xycom XVME-660 processor module

Product Details Introduction

Product Features of Xycom XVME-660 Processor Module

Xycom XVME-660 is a dual slot 6U VMEbus high-performance PC compatible processor module, equipped with Pentium III/Celeron processors, integrating PC ecology and VME bus reliability, focusing on high performance, rich scalability, and industrial grade stability, suitable for complex industrial control, data processing, and real-time embedded scenarios.

Equipped with * * Intel Pentium III (600/700MHz) or Celeron (566MHz) * * processors, supporting MMX instruction set, meeting high-performance real-time computing and multitasking requirements.

Compatible with IBM PC/AT standards, it can directly run PC/real-time operating systems such as Windows, DOS, VRTX, UNIX, etc., with a mature software ecosystem.

Onboard 64MB SDRAM, some versions support expansion up to 128MB, paired with CPU built-in cache to ensure smooth running of complex programs.

Integrated PCI EIDE, Ultra SCSI, 10/100Mbps Ethernet controller, providing high-speed storage and network communication capabilities.

Equipped with 2 high-speed RS-232 serial ports, 1 EPP/ECP parallel port, PS/2 keyboard and mouse interface, USB universal port, and comprehensive basic peripheral connectivity.

Supports VME64x protocol, compatible with VMEbus A32/A24/A16: D64/D32/D16 master/slave mode, efficient bus data transmission.

Built in 1 PMC expansion slot and 1 IP (Industry Pack) expansion slot, high-speed I/O and communication modules can be expanded without the need for an additional carrier board.

Adopting a dual slot 6U VME board structure, it has high mechanical strength and is compatible with standard industrial VME rack installation.

Industrial grade wide temperature design (-40 ℃~+85 ℃), resistant to electromagnetic interference, supports redundant power input, and operates stably in harsh environments.

Integrated hardware watchdog and real-time clock (RTC, with battery backup) to ensure automatic reset and time synchronization in case of system abnormalities.

The front panel integrates a status LED, which displays real-time CPU operation, bus activity, and fault status for easy on-site debugging and diagnosis.

Compatible with XVME series expansion modules (such as XVME-976/978), it can further expand PCI/PC/104/PMC and other interfaces, with flexible I/O configuration.

Supports VME standard power supply (+5V DC), with reasonable power consumption control, suitable for high-density rack deployment and long-term continuous operation.

Suitable for high-performance embedded scenarios such as industrial automation, DCS/PLC control, data acquisition, testing and measurement, aerospace, military electronics, etc.

XVME-660 Product imag

XVME-660 ontroller Module
