Product Details Introduction

XVME-500/1 is a classic 6U single high VME bus 12 bit analog input module from Xycom. It adopts a resistor selected gain design and is specifically designed for industrial high-precision analog signal acquisition.

6U single high VME architecture, single slot occupancy, compatible with standard VME backboards.

16 single ended (SE) or 8-differential (DI) analog inputs, expandable to 32SE/16DI.

12 bit A/D resolution, linearity ± 0.5 LSB, ensuring acquisition accuracy.

Input range: Unipolar 0-10V; Bipolar ± 5V, ± 10V.

On board resistor selection gain: 1, 10, 100, 1000 four levels, no software programming required.

Input impedance ≥ 10 M Ω, maximum input voltage 20V, common mode voltage 14V.

Common mode rejection ratio ≥ 60dB, strong resistance to on-site electromagnetic interference.

The maximum sampling throughput is 20 kHz, which meets the requirements of medium and high-speed data acquisition.

Occupy 1KB of VME short I/O address space, with optional base jumper.

Support interrupt triggered transitions, with configurable transition modes for status/control registers.

Power supply:+ 5V@1.6A (Typical)/1.9A (maximum), no additional auxiliary power supply.

Working temperature 0-65 ℃, storage -40-80 ℃, suitable for industrial environments.

Compatible with Analog Devices 3B series signal conditioning modules and compatible with various sensors.

Supports single channel random conversion and multi-channel scanning, with flexible programming.

Widely used in industrial automation, process control, data acquisition, testing and measurement scenarios.

Note: XVME-500/1 is an analog input module, not a processor module; The same series XVME-500/2 and 500/3 are programmable gain versions.

XVME-500/1 Product imag
