XYCOM XVME-956 Expansion Shelf Module

XYCOM XVME-956 Expansion Shelf Module

Product Details Introduction

XYCOM XVME-956 Expansion Carrier Module (PC/AT I/O Expansion Carrier)

XVME-956 is a single slot 6U VME bus I/O expansion bracket designed by XYCOM specifically for XVME-67x/68x series VMEbus PC/AT processor modules. It uses PC/104 open architecture to achieve flexible I/O expansion and is suitable for industrial control, data acquisition and other scenarios.

Adopting a single slot 6U VME bus structure, it only occupies one VME slot, saving rack space.

Built in 2 PC/104 open architecture extension bits, supporting PC/AT/XT interface submodules, compatible with third-party PC/104 modules.

Provide needle socket connectors (without card edge interface), with reliable connection and easy installation.

Supports original submodules such as XVME-956/101 memory module, 956/400 serial parallel port module, 956/402 SCSI adapter, 956/411 Ethernet module, etc.

Compatible with PC/AT architecture processor modules such as XVME-675 and 682, seamlessly expanding network, storage, serial port, and other functions.

The front panel integrates submodule I/O interfaces for easy on-site wiring and debugging.

The onboard power supply stabilizing circuit provides stable power supply for the PC/104 submodule, ensuring reliable operation of extended functions.

Industrial grade design, working temperature from 0 ℃ to+55 ℃, anti electromagnetic interference, suitable for industrial site environment.

Supports PC/AT standard bus protocol, compatible with operating systems such as DOS and Windows, and has a mature software ecosystem.

Adopting a dual board design (XVME-956/1 and 956/12), it is compatible with PC/104 modules of different sizes (Type A/B).

Supports diskless boot and is paired with solid-state storage submodules to enhance system reliability and vibration resistance.

Built in bus buffer and signal isolation protect the host and expansion module, enhancing system stability.

The front panel is equipped with a status LED, which displays the real-time working status of the power supply, bus, and submodules.

Compatible with VME64/VMEbus standards, supporting A32/A24/A16 address and D32/D16 data transmission.

Suitable for industrial automation, DCS control, data acquisition, testing and measurement, embedded real-time systems and other scenarios.
