XYCOM 3115T Industrial Touch Monitor Panel

XYCOM 3115T is a Thinline series 15 inch industrial grade integrated touch tablet PC that combines compact structure with industrial grade high reliability. It is designed to provide stable human-machine interaction solutions for demanding industrial scenarios such as production line monitoring, equipment control, and process visualization.

Core Features

15 inch color TFT LCD with XGA resolution of 1024 × 768, accurate color reproduction, clear and stable display.

8-wire analog resistive touch screen (4H surface hardness), supporting precise touch control, suitable for industrial sites with glove operation.

The front panel has a NEMA 4/12 and IP65 protection rating, with a sealed design that is dust-proof and splash proof, and can withstand workshop oil and moisture.

Equipped with Intel Socket 370 architecture Celeron/Pentium III processor (optional 850MHz/1.2GHz), the performance meets the requirements for industrial HMI and control program operation.

Standard 256MB SDRAM, expandable to 512MB, improves multitasking efficiency.

Built in 10/100Base-T Ethernet port, supporting high-speed industrial network communication and remote monitoring.

Integrate 2 RS-232 channels and 1 configurable RS-232/422/485 serial port, USB、 Complete I/O capabilities such as parallel port and VGA.

1 and a half long PCI expansion slots for easy installation of fieldbus or special communication modules.

Supports mainstream industrial operating systems such as Windows 2000/XP and MS-DOS, with strong driver compatibility.

Wide temperature operation (0 ℃~50 ℃), anti vibration, anti electromagnetic interference, in compliance with industrial IEC standards.

100-240VAC wide voltage supply (50/60Hz), with overvoltage and overcurrent protection.

Built in IDE hard drive, floppy drive, ultra-thin CD-ROM slot, optional flash module to meet program and data storage needs.

Tablet embedded installation, compact structure, all metal chassis, passive heat dissipation as the main feature, reducing the risk of fan failure.

Equipped with diagnostic LED and brightness adjustment, convenient for on-site status viewing and display parameter adjustment.

Compliant with CE and UL certifications, with long-term spare parts support, suitable for upgrading and replacing old industrial systems.

3115T   Product imag
