Xycom 8500 Operation Monitor Panel

Xycom 8500 is a classic heavy-duty industrial operator monitor designed for harsh on-site operations in refining, chemical, power, metallurgy, and other industries. It integrates dedicated display screens and physical keypad areas, supports panel/rack installation, and has strong protection and anti-interference capabilities. It is the core human-machine interaction device of early DCS/PLC systems.

Core Features

Monochrome high contrast CRT display screen, clear display without ghosting, suitable for strong and dim workshop environments, supports character/graphic display modes.

The front panel meets the NEMA 4/12 (IP65) protection standard, with a fully sealed design that is dustproof, oil resistant, splash proof, and can withstand harsh industrial conditions.

Integrated matrix digital buttons+function button area, paired with a rotating adjustment knob, supporting local fast parameter input and mode switching.

Compatible with industrial standard communication interfaces (primarily RS-232, optional RS-422/485), it can directly interface with mainstream PLC and RTU devices.

Wide voltage dual power supply (115/230VAC, 50/60Hz, 1.5/0.75A), universal for industrial power grids worldwide, with overvoltage and overcurrent protection.

Fanless pure passive cooling, all metal chassis, to prevent dust from entering and downtime caused by fan failure, and to improve system MTBF.

Wide temperature working range (0 ℃~50 ℃), resistant to strong vibration and electromagnetic interference (EMI/RFI), in compliance with IEC/EN industrial standards.

Built in multiple diagnostic indicator lights can quickly locate the operating status of key modules such as power supply, communication, and display.

Supports 19 inch standard rack installation or on-site panel embedded installation, with flexible installation methods and adaptability to control room and on-site cabinet layouts.

Modular design, key components can be quickly disassembled and replaced, and maintenance can be completed with three fixed screws, greatly reducing downtime.

Supports industrial grade character based HMI software and DOS underlying drivers, compatible with early industrial control programs, without the need for large-scale secondary development.

The standard hardware watchdog circuit can automatically detect system crashes and perform resets, ensuring continuous operation under unmanned conditions.

Compliant with UL, CE, and CSA industrial certifications, with comprehensive electrical isolation and surge protection design.

Low power stable operation, suitable for long-term deployment in remote areas and air-conditioned computer rooms, reducing operation and maintenance costs.

8500   Product imag
