E84DHMFC1524R6 frequency converter

E84DHMFC1524R6 frequency converter

Product Details Introduction

Equipped with 32-bit PSOC ™  Edge multi-core processor, fast computing speed, control response without delay under complex loads.

Support torque vector control and V/F curve self optimization, increase low-speed torque to 150% of rated torque, suitable for heavy-duty starting scenarios.

The output frequency range is 0.1~600Hz, with a frequency accuracy of ± 0.01%, meeting the requirements of high-precision speed regulation.

Compatible with SEMI E84 communication protocol, seamlessly integrated with semiconductor AMHS system, supporting bidirectional data exchange between device and host.

Integrated Modbus and Ethernet interfaces, can be directly linked with COR-3/230R modules, making multi device collaborative control convenient.

Working temperature coverage -10~55 ℃, wide temperature design suitable for complex temperature zones in industrial workshops, excellent stability.

Built in 17 motor protection functions (overcurrent/overvoltage/overload/overtemperature/phase loss/locked rotor, etc.), fully safeguarding equipment safety.

Supports S-curve/linear acceleration/deceleration mode, with adjustable acceleration/deceleration time ranging from 0.1 to 3600 seconds to prevent load shock.

380VAC wide voltage input (± 15% fluctuation tolerance), strong resistance to grid interference, suitable for power supply conditions in multiple regions.

Modular heat dissipation structure+intelligent fan speed regulation, low-power design, noise ≤ 60dB, in compliance with green industry standards.

Support parameter self-tuning and offline backup, high efficiency for batch deployment, and adaptability to large-scale production debugging needs.

Equipped with jump frequency setting function, it can avoid mechanical resonance points and adapt to fluid loads such as fans and pumps.

Support remote diagnosis and fault alarm, LED status indication+fault code display, fast and efficient problem troubleshooting.

Suitable for semiconductor manufacturing, automated conveyor lines, machine tool spindles, and other scenarios, compatible with COR-3/230R module control requirements.

Electronic thermal overload protection can accurately match motor parameters, eliminating the need for external thermal relays in "one to one" scenarios and simplifying circuit design.

E84DHMFC1524R6  Product imag
