COR-3/230R motion control module

COR-3/230R motion control module

Product Details Introduction

Support multi axis linkage control, expandable up to 64 axes, to meet complex trajectory motion requirements and adapt to large-scale equipment.

The pulse output frequency is high, with a positioning accuracy of ± 0.001mm, and the COR-3/230R dynamic control response is fast and hysteresis free.

Compatible with three modes of position/speed/torque, the control mode can be flexibly switched through pulse, analog quantity or bus.

Integrated RS232/485 and Ethernet interfaces, compatible with mainstream protocols such as Modbus, and easy to interface with PLC/DCS systems.

The working temperature covers -10~60 ℃, with strong temperature tolerance and adaptability to complex temperature zones in industrial workshops.

Equipped with current isolation and anti electromagnetic interference design, COR-3/230R signal transmission is stable and distortion free, with excellent anti-interference performance.

Built in multiple protections for overcurrent, overvoltage, and overload, comprehensively safeguarding the safe operation of modules and actuators.

Support position synchronization output (PSO) function, suitable for high-precision synchronization control scenarios such as laser firming.

24VDC wide voltage input design, strong resistance to grid fluctuations, suitable for power supply conditions in multiple regions.

Modular plug-in structure, easy installation and disassembly, significantly reduces maintenance costs for COR-3/230R.

Support parameter self-tuning and offline backup, high efficiency for batch deployment, and adaptability to large-scale production needs.

Motion parameters are mapped to a dedicated addressing space, axis resources are flexibly allocated, and unused resources can be used as ordinary components.

Fanless low-power design, efficient heat dissipation and low noise, in line with green industrial production standards.

Suitable for machine tools, robotic arms, automated conveyor lines and other equipment, with a wide range of industrial application scenarios.

Support remote diagnosis and fault alarm, clear LED status indication, fast and efficient problem troubleshooting.

COR-3/230R  Product imag

COR-3/230R  ontroller Module
