P0914XG FBM205 Input/Output Isolation Module

P0914XG FBM205 Input/Output Isolation Module

Product Details Introduction

P0914XG FBM205 Input/Output Isolation Module Product Features

4-in-4-out redundant configuration: 4-channel redundant 0-20mA analog input, 4-channel redundant 0-20mA analog output, supporting 4-20mA standard signals, compatible with transmitters and actuators.

Full channel electrical isolation: Input/output channels, channel to ground, and channel to module logic are all electrically isolated, with a voltage withstand of 2500V, strong anti-interference, and anti ground circulation.

Module level redundant architecture: paired master/slave redundancy, sharing on-site terminals; When the main module fails, the output can be configured for fault safety (hold/reset) without disturbance from the module.

High precision ∑ - Δ conversion: Single channel ∑ - Δ analog-to-digital/digital to analog conversion, accuracy ± 0.1% FS, 12 bit resolution, meeting the accuracy requirements of process control.

Improve diagnosis and safety: support channel disconnection, over range, module failure, and temperature anomaly diagnosis; Output can set fault safety actions to adapt to process safety requirements.

Redundant circuit power supply: Provide redundant circuit power supply for on-site transmitters to avoid signal interruption caused by single point power failure.

Hot swappable and easy to maintain: supports online hot swappable, replacement does not require system shutdown, reducing the impact of maintenance on production.

Industrial grade environmental adaptation: Operating temperature -20 ℃~+70 ℃, anti vibration and anti impact, in compliance with G3 level harsh environmental standards.

Standardized installation and wiring: compatible with standard guide rails and terminal components, flexible local/remote wiring, and convenient construction and debugging.

Native compatibility with Foxboro system: seamless integration of I/A Series and Evo DCS, easy configuration, stable and reliable data transmission.

P0914XG FBM205 is designed with redundancy, reliability, full isolation, and high precision as its core, specifically for high safety and high availability analog I/O scenarios. It is the preferred module for signal acquisition and control in harsh working conditions such as chemical, power, and petroleum industries.

P0914XG FBM205 Product imag

P0914XG FBM205 ontroller Module
