IC697CGR772 processor unit module

IC697CGR772 processor unit module

Product Details Introduction

IC697CGR772 processor unit module (15 key points)

Specially designed for GE Fanuc 90-70 series PLC, it is a high-performance CPU module with hot standby redundancy and dual bus architecture.

Using an 80486 DX4 96MHz processor, it supports 32-bit floating-point operations and can execute a single Boolean instruction in just 0.4 μ s.

Single slot compact design, occupying one standard slot on 90-70 backboards, compatible with standard and VME integrator backboards.

Built in 512KB battery backup CMOS RAM, long-term storage of programs and data after power failure, equipped with IC697ACC701 lithium battery.

Support hot standby redundancy, achieve interference free switching, CPU synchronization, redundant communication, with switching time ≤ 1 scan cycle.

Equipped with a dual bus architecture, compatible with IC660/IC661 Genius bus and IC697 local I/O, with strong hybrid I/O expansion capability.

Maximum I/O capacity: 2048 DI+2048 DO, analog I/O supports up to 8000 points, suitable for large-scale systems.

Provide 3 independent SNP serial ports (1 × RS232, 2 × RS485), supporting programming, monitoring, and communication with third-party devices.

Full software configuration, no hardware jumpers/dials, configured through Logicmaster 90-70, easy to operate.

Built in battery backup real-time clock (RTC), precise timestamp, meeting the needs of process traceability and timing control.

Equipped with 7 LED status indicator lights, real-time display of operation, communication, fault, low battery status, etc., providing intuitive diagnosis.

Support online programming and maintenance, redundant systems can be maintained with a single module without interrupting production operations.

Equipped with three-level operation mode switch (run/program/protect)+password+key lock, triple data security protection.

Backboard * *+5V power supply, current requirement of about 1.3A * *, no additional power supply required, simple deployment.

Industrial grade wide temperature range (-40 ℃~+85 ℃), anti vibration design, certified as Class I Div 2 explosion-proof, suitable for harsh environments.

IC697CGR772 is a highly reliable, redundant, and high-performance core CPU for the 90-70 system, and is the preferred control unit for continuous production industrial scenarios.

IC697CGR772 Product imag

IC697CGR772 ontroller Module
