Product Details Introduction

IC697ALG440 Current Expander Module Product Features

IC697ALG440 is a 16 channel current input expansion module specifically designed for GE Fanuc 90-70/90-30 series PLCs. It must be used in conjunction with the IC697ALG230 basic converter module to form a complete analog input subsystem.

16 channel independent configuration: 16 differential input channels, each channel can be independently configured for 4-20mA current or * * ± 10V voltage * * signal, without the need for hardware jumpers.

High precision 12 bit ADC: 12 bit analog-to-digital conversion, 4096 level resolution, meeting the accuracy requirements of industrial process monitoring and control.

Flexible Expansion Architecture: Combined with ALG230 basic modules, a single system can expand up to 120 analog input channels, suitable for large-scale I/O scenarios.

Full software configuration: Channel type, range, scaling and other parameter configurations are completed through Windows/DOS software, making debugging convenient.

Overvoltage/Transient Protection: The input channel is equipped with built-in overvoltage and transient protection to enhance the system's anti-interference and stability.

LED status diagnosis: Module and channel status LEDs quickly locate operational/fault information for easy maintenance.

Hot swappable compatibility: supports online hot swappable, module replacement does not require system shutdown, reducing production impact.

Industrial grade reliable design: single slot installation, wide temperature operation, anti vibration and impact, suitable for harsh working conditions such as chemical, power, metallurgy, etc.

Native system compatibility: Seamless integration with GE Fanuc 90-70/90-30 PLC system, stable and reliable backplane communication.

Non volatile storage calibration: Factory calibration data is stored in EEPROM, ensuring long-term stability without frequent calibration.

IC697ALG440, with high-density expansion, flexible configuration, and high reliability as its core, is a key expansion module for building large-scale analog input systems for GE 90 series PLCs.

IC697ALG440  Product imag

IC697ALG440  ontroller Module
