Product Details Introduction

P0914TR FBM217 Isolation Monitor (Voltage/Discrete Input Module)

Belonging to the Foxboro I/A Series DCS system, it is a 32 channel group isolated discrete input/voltage monitor module.

Adopting a group isolation design, the channel group is fully isolated from the system and ground, with a tolerance of 600VAC/1min, strong anti-interference, and anti ground circulation.

Supports multi voltage level inputs of 15-60VDC, 120VAC/125VDC, and 240VAC, suitable for dry contact/wet contact/voltage monitoring scenarios.

Single channel typical input current 2.2mA@30VDC The conduction threshold is 15-30VDC, and the turn off threshold is 0-5VDC, ensuring accurate signal recognition.

Built in signal filtering and stabilization, with software configurable filtering parameters to enhance the stability of complex on-site signals.

24VDC redundant power supply, maximum power consumption of 3W, safe and reliable power supply.

Equipped with LED status indicator lights, it intuitively displays the operation, communication, and channel input status of the module, facilitating quick diagnosis.

Support redundant 2Mbps fieldbus communication to ensure stable data exchange with FCM/FCP controllers.

Support online hot plugging, maintenance does not require power outage or disconnection, and does not affect the continuous operation of the system.

Industrial grade wide temperature design, working temperature range of * * -40 ℃~+85 ℃ * *, meeting the strict industrial environment standards of G3.

Modular structure, DIN rail installation, paired with P0914TR terminal assembly, easy deployment and wiring.

Seamless integration of I/A Series control system, supporting online diagnosis, status monitoring, and SOE event sequence recording.

Suitable for switch quantity collection, voltage monitoring, equipment status feedback, and safety interlocking scenarios in industries such as petrochemicals, power, metallurgy, and water treatment.

This module, with its core advantages of 32 channel high density, group isolation high reliability, multi voltage compatibility, and easy maintenance, is a key component for discrete signal and voltage monitoring in industrial DCS systems. It can efficiently meet the needs of large-scale on-site signal acquisition and safety monitoring.

P0914TR FBM217 Product imag
