IC697ALG320 Analog Output Module

IC697ALG320 Analog Output Module

Product Details Introduction

IC697ALG320 Analog Output Module Product Features

4-channel independent configuration: 4-channel independent output channels, each channel can be individually set to voltage/current mode by software, without the need for hardware jumpers.

Wide range signal output: voltage support 0-10V/± 10V; current support 4-20mA/0-22.5mA, suitable for various actuators.

16 bit high-precision DAC: 16 bit resolution (voltage 312.5 μ V/step, current 0.5 μ A/step), 14 bit monotonicity, high conversion accuracy.

Fast update rate: The maximum time for full channel sequential conversion is 2.0ms, meeting the real-time requirements of closed-loop control.

Channel Backplane Electrical Isolation: The output is electrically isolated from the backplane, with overvoltage/short circuit protection to enhance system anti-interference and safety.

Flexible software configuration: Full parameter software configuration, supporting single/double polarity, range scaling, and easy debugging.

Factory calibration+EEPROM storage: Factory calibration, data stored in non-volatile EEPROM, long-term stability without frequent calibration.

LED status diagnosis: Module and channel status LED, quickly locate operation/fault information.

Industrial grade reliable design: single slot installation, wide temperature operation, anti vibration and shock resistance, suitable for harsh industrial environments.

Series 90-70 native compatibility: seamless integration with GE Fanuc 90-70 PLC system, stable backplane communication.

IC697ALG320 is the preferred module for analog output and actuator control in the GE 90-70 system, with high precision, flexible configuration, strong isolation, and high reliability as its core.

IC697ALG320 Product imag
