IC697CHS771 processor module

Product Details Introduction

1、 Core Performance and Architecture

Processor: 12MHz 80C186 16 bit CPU, Boolean instruction execution speed of 0.4 μ s.

Memory: Single slot expandable to 512KB battery backup RAM, configurable program/data partitioning.

I/O capability: Supports up to 2K discrete I/O (any mix)+8K analog I/O.

Slot: Single slot design, compatible with 90-70 standard VME backboards.

2、 Data and reliability

Battery backup: Built in lithium battery, maintains program/data+calendar clock in case of power failure.

Security: Third level password protection to prevent unauthorized access and modification.

Configuration: Pure software configuration, no DIP switches/jumpers, simplified deployment.

3、 Communication and Interface

Backboard: VME C. 1 standard, high-speed connection between I/O and intelligent modules.

Programming port: Supports serial/parallel/Ethernet, compatible with MS-DOS/Windows programming software.

Expansion bus: Supports Genius, IC660/IC661 remote I/O, and third-party communication modules.

4、 Operation and Status

Three level switch: RUN/STOP/REMOTE, local/remote control switching.

LED indication: Visual diagnosis of operation, fault, and communication status.

Hot swappable: supports online replacement and maintenance without interrupting production.

5、 Industrial specifications

Power supply: 5V DC, typical current 1.5A.

Temperature: 0-60 ℃, suitable for industrial site environment.

Application: Real time control systems for machine tools, packaging lines, process control, material handling, etc.

IC697CHS771 Product imag


IC697CHS771 ontroller Module
