HESG447224R0002 70AB01C-ES control board

HESG447224R0002 70AB01C-ES control board

Product Details Introduction

HESG447224R0002 70AB01C-ES Control Board (Binary Signal Output Control Board) Core Points

This model is an ABB Procontrol P13/HSC system specific binary signal output control board, which focuses on 16 independent digital output control and is suitable for high reliability switch driving scenarios in industrial sites. The 15 differentiated core points are as follows:

Exclusive adaptation to ABB Procontrol P13/HSC system, directly connected to the system bus, no additional communication adaptation module required, plug and play

Configure 16 independent binary output channels, each of which can be independently configured to meet the needs of multiple switch control

Single channel continuous output current of 2A, peak value of 3A, suitable for conventional industrial loads such as solenoid valves and contactor coils

Electrical isolation between channels to avoid signal crosstalk, single channel failure does not affect the normal operation of other channels

Built in dual protection against short circuit and overload, preventing damage to the control board and backend equipment caused by external load faults

Channel level LED status indicator light, real-time visibility of on/off/fault status, no additional testing tools required for on-site troubleshooting

Industrial grade wide temperature design, able to withstand temperature fluctuations from -25 ℃ to+70 ℃, suitable for working conditions with high dust and strong electromagnetic interference

Standard DIN rail installation, buckle fixation, anti loosening terminal block, suitable for vibration industrial environment

Suitable for 24V DC standard control voltage, compatible with commonly used low-voltage DC drive circuits in industry

Support online hot plugging (meeting system operating standards), maintenance and replacement do not require shutting down the entire control system

Support output parameter configuration through system programming software, no need to manually adjust potentiometers, efficient debugging

Pneumatic/hydraulic actuator switch control adapted for industrial automation production lines, ensuring precise execution of actions

Compatible with ABB Freelance Control software, achieving integration of configuration, debugging, and fault diagnosis

Adopting industrial grade flame-retardant PCB and components, in compliance with IEC/EN industrial electrical safety standards, ensuring safe operation

The module has low power consumption, no additional heat dissipation requirements, and can be densely installed in the control cabinet, saving installation space

HESG447224R0002 70AB01C-ES Product imag

HESG447224R0002 70AB01C-ES ontroller Module

PROSOFT MVI56E-MCM communication module
EMERSON SLS1508 Relay Module
PROSOFT MVI56E-MNETCR communication module
