00-128-377 Communication Interface Module

00-128-377 Communication Interface Module

Product Details Introduction

00-128-377 is a Gateway A+CI3 Bus communication gateway module (including supporting cables) specifically designed for KUKA KRC2/KRC2 ED05 control cabinets. Its core function is to achieve protocol conversion and data exchange between robot controllers and external industrial bus devices (such as Interbus, Profibus, etc.). It is the core hardware for expanding external bus communication in the KRC2 system.

Product features (15 items)

Adaptation system: specially designed for KUKA KRC2 and KRC2 ED05 control cabinets, deeply compatible with CI3 control modules and MFC3 motherboards.

Core positioning: As a Gateway A, responsible for protocol conversion and data forwarding between the internal bus of the robot and the external industrial fieldbus.

Bus compatibility: Supports mainstream industrial fieldbus protocols such as Interbus and Profibus DP, and is compatible with multiple brands of PLCs and automation equipment.

Internal interface: Integrated CI3 Bus internal bus interface, directly communicates with the controller core module, ensuring stable and efficient data transmission.

External interface: equipped with standard fieldbus physical interfaces (such as D-Sub, terminal block), supporting cascading expansion of external bus devices.

Protocol conversion: Real time bidirectional conversion between internal robot data and external bus protocols to ensure real-time data exchange.

Data transmission: Supports high-speed data transmission to meet the real-time control and data acquisition needs of industrial production lines.

Status indication: Onboard multi-color LED indicator lights, real-time display of bus communication, data transmission and reception, faults, and operating status.

Power supply method: Powered by a 24V DC auxiliary power supply from the control cabinet, no additional independent power supply is required, simplifying system wiring.

Hardware integration: Gateway A and CI3 Bus integrated design, including dedicated connection cables, plug and play installation.

Strong compatibility: Seamless integration with KUKA standard bus modules and external bus master/slave devices, compatible with KRC2 full range configurations.

Protection level: IP20, only suitable for installation inside control cabinets, dust-proof and touch proof, suitable for industrial workshop environments.

Working temperature: 0-55 ℃, stable operation over a wide temperature range, meeting the all-weather working requirements of the production line.

Modular design: standard cabinet slot installation, supports quick insertion and replacement, and is easy to maintain.

Certification compliance: Through industrial safety certifications such as CE and UL, it meets international industrial standards and is compatible with global automation production lines.

00-128-377 Product imag
