00-108-036 I/O board unit

00-108-036 I/O board unit

Product Details Introduction

00-108-036 is a standard digital I/O interface board dedicated to KUKA KRC2/KRC2 ED05 control cabinet. Its core function is to achieve digital signal interaction between robot controllers and external devices, providing stable 24V DC input/output channels. It is the core hardware for the basic I/O expansion of KRC2 system.

Product features (15 items)

Adaptation System: Designed specifically for KUKA KRC2 and KRC2 ED05 robot control cabinets, compatible with control modules such as MFC3 and CI3.

Channel configuration: Standard configuration includes 16 digital inputs (DI) and 16 digital outputs (DO), totaling 32 basic I/O channels.

Input type: Digital input is 24V DC NPN/PNP compatible, supporting dry contact and active sensor signal access.

Output type: Digital output is 24V DC transistor output, with a maximum single channel driving current of 0.5A, suitable for loads such as solenoid valves and relays.

Interface form: Standard terminal block wiring is adopted, with clear channel numbering, supporting fast on-site wiring and maintenance.

Signal isolation: The input/output channels are optically isolated, with strong anti-interference ability, protecting the controller from external surge impact.

Status indication: Each DI/DO is equipped with an independent LED indicator light, which displays real-time signal on/off for quick diagnosis.

Power supply: Powered by a 24V DC auxiliary power supply from the control cabinet, no additional independent power supply is required, simplifying system wiring.

Address configuration: Supports hardware address dialing or software configuration, can be cascaded and expanded with other I/O boards, and flexibly adapts to different I/O requirements.

Communication interface: Communicate with the controller CPU through an internal bus (such as DSE-IBS), with high real-time signal transmission.

Protection level: IP20, only suitable for installation inside control cabinets, dust-proof and touch proof, suitable for industrial environments.

Working temperature: 0-55 ℃, stable operation over a wide temperature range, meeting the all-weather work requirements of the workshop.

Modular design: Standard PCI/slot installation, supports hot plugging (power-off operation), and replacement does not require complex debugging.

EMC compatibility: Industrial grade electromagnetic compatibility design, compliant with EN 61000 standard, resistant to strong electromagnetic interference in the workshop.

Certification compliance: Through industrial safety certifications such as CE and UL, it is suitable for global automation production line applications.

00-108-036 Product imag

00-108-036 ontroller Module
