00-115-631 safety board

00-115-631 safety board

Product Details Introduction

00-115-631 is a SafetyBUS network gateway board dedicated to KUKA KRC2/KRC2 ED05 control cabinet. Its core function is to achieve bus based communication and safety signal interaction between robot safety system and external safety devices (such as emergency stop, safety door, grating). It is the core communication module of KRC2 safety circuit.

Product features (15 items)

Adaptation system: specially designed for KUKA KRC2 and KRC2 ED05 robot control cabinets, deeply compatible with ESC safety circuits and CI3 control modules.

Bus type: SafetyBUS communication is adopted, which meets industrial safety standards and supports safety level signal transmission.

Communication function: As a security bus gateway, responsible for the collection, transmission, and logical processing of security signals, connecting security master and slave devices.

Safe Channel: Provides dual channel redundant secure communication, single channel failure does not affect safety functions, and meets SIL2 safety level requirements.

Signal processing: Real time processing of emergency stop (ES), safety door, grating, enable switch and other safety signals, quickly triggering safety shutdown in case of faults.

Interface configuration: Equipped with a SafetyBUS p dedicated interface, supporting cascading of multiple safety devices and expanding safety I/O nodes.

Status indication: Onboard multi-color LED indicator light, real-time display of bus communication, safety circuit, fault and operation status.

Power supply method: Independently powered by the 24V DC auxiliary power supply of the control cabinet, ensuring that the power supply of the safety system is not affected by fluctuations in the main power supply.

Hardware compatibility: seamlessly integrate with KUKA standard security modules (such as ESC-CI, SIB) and adapt to the full range of KRC2 security configurations.

Communication rate: The SafetyBUS p-bus communication rate is stable, meeting the requirements of real-time and reliability of safety signals.

Protection level: IP20, only suitable for installation inside control cabinets, dust-proof and touch proof, suitable for industrial workshop environments.

Working temperature: 0-55 ℃, stable operation over a wide temperature range, meeting the all-weather working requirements of the production line.

Modular design: standard cabinet slot installation, supports quick insertion and replacement, and is easy to maintain.

EMC compatibility: Industrial grade electromagnetic compatibility design, resistant to strong electromagnetic interference in the workshop, ensuring safe and stable communication.

Certification compliance: Through CE, T Ü V and other safety certifications, it meets international industrial safety standards and is compatible with global automation production lines.

00-115-631 Product imag
