KCP2 00-131-239 Control Panel

KCP2 00-131-239 Control Panel

Product Details Introduction

KCP2 00-131-239 is a standard handheld teaching pendant tailored by KUKA for the KRC2 ED05 control cabinet. It belongs to the core model of KCP2 series and is used for robot programming teaching, manual control, status monitoring and safety intervention. It achieves high reliability communication with the controller through CAN bus and is the core human-machine interaction terminal for KRC2 ED05 workstation debugging and production operation.

Product features (15 items)

System adaptation: Exclusive adaptation to KUKA KRC2 ED05 control cabinet, fully compatible with MFC3 motherboard and CI3 bus module, with no compatibility redundancy.

Core positioning: Integrating programming, teaching, debugging, monitoring, and safety control, it is the only standard handheld operating unit for the KRC2 ED05 system.

Display specifications: Equipped with an 8-inch color TFT LCD screen with a resolution of 640 × 480 (VGA), the graphical interface clearly presents programs, coordinates, alarms, and I/O status.

Operation layout: Using a combination of film keyboard and 6D mouse, combined with physical buttons such as mode selection, servo start stop, emergency stop, etc., to balance precise control and blind operation efficiency.

Communication architecture: The main communication is the CAN bus (transmitting keys and security status), and display data is transmitted through an independent high-speed serial port, with dual channels ensuring stable communication.

Safety system: Integrated dual channel emergency stop button and three position enable switch (Deadman), in compliance with EN ISO 10218 industrial robot safety standards, ensuring mandatory human-machine safety.

Mode switching: support * * T1 (manual low speed), T2 (manual high speed), AUT (automatic) * * three modes, knob switching, adapt to the full scene requirements from debugging to mass production.

Interface configuration: Equipped with RJ45 Ethernet, 9-pin D-Sub, DIN socket, supporting program backup and archiving, external MF II keyboard and peripheral expansion.

Power supply design: 24V DC direct power supply is provided by the control cabinet through a dedicated connection cable, with a power consumption of ≤ 10W, without the need for an independent power supply, simplifying on-site wiring.

Program management: supports program creation, editing, copying, deletion, backup, and recovery, supports online modification of motion parameters and logic, greatly improving debugging efficiency.

Diagnostic capability: Real time display of robot coordinates, speed, load, tracking error, alarm codes, built-in fault location guidance, and reduced maintenance downtime.

Protection performance: IP65 protection for the front panel, preventing oil, dust, and coolant splashing; The shell is made of high-strength engineering plastic, which is resistant to falling and impact.

Human engineering: Ergonomic curved design, center of gravity fits handheld posture, weight optimized to about 3.8kg, and not easily fatigued during long-term operation.

Environmental adaptation: Operating temperature of 0-50 ℃, storage temperature of * * -20-60 ℃ * *, wide temperature operation, suitable for harsh industrial scenarios such as automotive manufacturing and welding.

Certification compliance: Passed CE, UL, cUL certifications, meets RoHS environmental requirements, and meets global industrial site access standards.

KCP2 00-131-239 Product imag
