07AA63R1 GJV3074368R1 Analog Output Module

07AA63R1 GJV3074368R1 Analog Output Module

Product Details Introduction

Key Points of 07AA63R1 GJV3074368R1 Analog Output Module

07AA63R1 (GJV3074368R1) is a dedicated analog output module for ABB AC31 series PLC, featuring 4-channel 0-10V voltage type analog output. It is designed specifically for continuous adjustment in industrial sites, with 15 differentiated core points as follows:

Exclusive adaptation to ABB AC31 series PLC, seamless compatibility with backplane bus, no additional adapter accessory requirements

Configure 4 independent 0-10V voltage output channels, single channel can be independently configured and set, suitable for multiple control requirements

8-bit DAC digital to analog conversion resolution, meeting the accuracy requirements of industrial conventional continuous process control

Electrical isolation design between each output channel thoroughly avoids signal crosstalk between channels and improves output stability

Built in dual protection mechanism for output short circuit and overload, effectively protecting the module and external execution equipment

Equipped with channel level fault indicator lights, the operation/fault status is intuitively visible, and on-site troubleshooting does not require additional instruments

Industrial grade wide temperature design, resistant to temperature and humidity fluctuations in industrial sites, suitable for working conditions with high dust and strong electromagnetic interference

Standard PLC rail installation, with anti loosening design for wiring terminals, convenient wiring and anti vibration loosening

No external calibration potentiometer, zero and full-scale calibration can be completed through PLC programming software, with efficient operation

Adapting to standard industrial load impedance, it can directly drive devices such as frequency converters, electric control valves, analog instruments, etc

Low module power consumption, no additional heat dissipation requirements, can be densely installed in PLC control cabinets, saving space

Support online hot plugging (must meet AC31 series operating specifications), maintenance and replacement do not require shutting down the entire control system

Excellent linearity of output signal, no drift, and continuous operation for a long time can still ensure control accuracy

Compatible with ABB Freelance Control software, integrated configuration, parameter settings, and program debugging are completed

The whole machine adopts industrial grade flame-retardant components, which comply with industrial electrical safety standards and have high operational safety

07AA63R1 GJV3074368R1 Product imag

07AA63R1 GJV3074368R1  ontroller Module
