0GH-IP161 Analysis Input Module

0GH-IP161 Analysis Input Module

Product Details Introduction

B&R 0GH-IP161 is a programmable analysis input module from the B&R 2005 SYSTEMS series in Austria, designed specifically for industrial automation signal acquisition and analysis scenarios.

Supports 12 digital input channels, compatible with 24VDC standard industrial signals, using sink input method for stable and reliable signal reception.

Equipped with 6 high-precision 14 bit analog input channels, the measurement range covers ± 10V, and can accurately collect analog signals from sensors, transmitters, and other devices.

Integrated 6 channels of 12 bit analog output, also supporting ± 10V output, can directly drive actuators or feedback control signals, achieving closed-loop control.

Built in 850KB SRAM and 1.5MB FlashPROM storage unit, supporting local data caching and offline program operation, ensuring signal processing continuity.

Standard RS232 serial communication interface and electrically isolated CAN bus interface, supporting network interconnection for seamless integration with PLC and upper computer.

The protection level meets industrial standards, is suitable for installation in control cabinets, can withstand dust interference in industrial sites, and protects the stable operation of internal circuits.

B&R 0GH-IP161 has a short response time for digital input and a high refresh rate for analog acquisition, which can meet the requirements of high-frequency signal detection and real-time control.

Supporting independent channel configuration, the input signal type and filtering parameters can be flexibly set according to on-site needs, and adapted to multiple sensor access.

Built in overvoltage and overcurrent protection mechanisms, set current limiting protection for analog channels, and comprehensively safeguard the safety of modules and front-end devices.

Compatible with B&R Automation Studio programming software, supports graphical configuration and parametric settings, and has convenient and efficient debugging operations.

Adopting standardized module design, supporting DIN rail installation, with clear definition of wiring terminals, simple installation and disassembly, and low maintenance costs in the later stage.

The working temperature range is suitable for the conventional requirements of industrial scenarios, and can operate stably in most factory buildings, computer rooms, and other environments, with strong environmental adaptability.

Excellent mean time between failures (MTBF) performance, strict selection of core components, outstanding long-term operational reliability, and reduced system downtime losses.

Widely used in automated production lines, process control systems, intelligent detection equipment and other scenarios, especially suitable for industrial scenarios that require synchronous acquisition of multiple types of signals.

0GH-IP161 Product imag
