PCS124PS-200 power module

PCS124PS-200 power module

Product Details Introduction

PCS124PS-200 power module product features

1. Rated power of 200W, supporting 115% peak overload (230W), with a duration of up to 60 seconds, suitable for short-term high load conditions.

2. Deeply cultivate 24V DC output scenarios, with voltage accuracy controlled within ± 0.8% and ripple noise ≤ 50mV, suitable for precision equipment power supply.

3. Adopting an isolated topology design, the input and output isolation voltage reaches 2250VDC, the insulation resistance is ≥ 200M Ω, and the electrical safety is fully ensured.

4. Wide DC input range of 18-36VDC (4:1 aspect ratio), compatible with 24V battery packs and industrial standard power supply circuits, with strong adaptability.

5. The energy conversion efficiency is as high as 93.5%, and the no-load power consumption is less than 1W, which combines energy saving and long-term operation stability.

6. Supports adjustable output voltage of ± 10%, coupled with remote sensing function, can accurately compensate for line voltage drop, ensuring stable terminal voltage.

7. Built in intelligent temperature control and heat dissipation system, combining natural convection and auxiliary heat dissipation, with a working noise as low as 30dB and no hidden danger of fan wear.

8. Excellent tolerance to extreme environments, with a working temperature range of -40 ℃~70 ℃, and stable operation within an altitude of 5000m (with moderate derating beyond 3000m).

9. Upgrade multiple protection mechanisms, add reverse protection and surge protection (± 2kV), and equip with over temperature, over-current, and short-circuit self recovery functions.

10. Support remote on/off control, response delay ≤ 400 μ s, can be integrated into automated control systems for centralized operation and maintenance.

11. Adopting a sealed metal shell design, the protection level reaches IP21, and the impact and vibration resistance performance meets industrial standards, suitable for harsh environments.

12. Suitable for TS-35 standard DIN rail installation, with a width of only 40mm, it can be densely deployed in electrical control cabinets, saving installation space.

13. Built in secondary EMI filter, compliant with EN 55022 electromagnetic compatibility standard, with no electromagnetic radiation interference to peripheral equipment operation.

14. The mean time between failures (MTBF) exceeds 500000 hours, and after 100% full load aging testing, the service life can reach more than 8 years.

15. Equipped with cage type terminal blocks, the wiring is firm and anti drop, matched with multi-color markings, making installation and maintenance convenient and efficient.

PCS124PS-200 Product imag
