IMDSO02 Digital Output Module

IMDSO02 Digital Output Module

Product Details Introduction

IMDSO02 Digital Output Module Product Features (15)

1. Configure 8 independent transistor output channels, using PNP source output mode, dedicated 24VDC load adaptation, and response speed better than relay type modules.

2. The rated output current of a single channel is 2A, the peak load current can reach 3A, the contact withstand voltage is 30VDC, and it accurately drives small solenoid valves, indicator lights, and other precision actuators.

3. The output response delay is as low as 50 μ s (on)/100 μ s (off), supporting 100Hz high-frequency switching action, suitable for high-speed cyclic control scenarios.

4. Deeply compatible with ABB Beli INFI 90 DCS system, it can directly replace old modules without the need to reconstruct control programs and hardware architecture, with low upgrade costs.

5. The channel and backplane bus are designed with optoelectronic isolation, with an isolation voltage of up to 2500VAC, paired with RS485 interface 600W surge protection, and upgraded anti-interference capability.

6. Native support for Modbus RTU protocol, expandable PROFINET communication module, achieving seamless integration with heterogeneous controllers such as Siemens and Rockwell.

7. The wide temperature working range covers -30 ℃ to 60 ℃, and the load capacity of high temperature working conditions is adaptively adjusted when installed horizontally, suitable for high-altitude and low-temperature industrial scenarios.

8. Built in module level power monitoring and channel level short circuit protection, automatically shuts off the channel and reports an alarm when a fault occurs, avoiding bidirectional damage between the load and the module.

9. Equipped with a three color LED indicator light group, green indicator channel output, red fault prompt, and yellow feedback power status, the operation and maintenance diagnosis is intuitive and efficient.

10. Adopting an ultra compact design with a width of only 15mm and standardized DIN rail installation, it greatly saves installation space inside the control cabinet and facilitates dense layout.

11. Supports PWM pulse width modulation output, and can achieve stepless speed regulation and dimming control of the actuator through duty cycle adjustment, with stronger functional scalability.

12. Equipped with mechanical coding key positioning function to prevent module misplacement and installation, coupled with automatic coding recognition, there is no need to manually configure the address after connecting to the system.

13. Adopting a 9-27VDC wide power supply design, it has reverse connection protection function to avoid module burnout caused by on-site wiring errors, and has better safety.

14. Support two channel parallel redundant control, which can improve the reliability of key load driving and adapt to industrial scenarios with high requirements for continuous operation.

15. Adopting surface mounted components and sealed packaging technology, the power consumption is as low as 1W, and the fanless design ensures better long-term stability than conventional modules.

16. Compliant with UL, CE, and IEC 61131-2 standards, with multi-dimensional industrial certification, widely applicable in scenarios such as water treatment, automated production lines, logistics and warehousing.
