IMDSO01 Digital Output Module

IMDSO01 Digital Output Module

Product Details Introduction

IMDSO01 Digital Output Module Product Features (15)

1. Configure 8 independent digital output channels, support relay dry contact output, compatible with 24VDC/220VAC loads, and adaptable to multiple types of actuators.

2. The maximum load current of a single channel can reach 5A, and the contact withstand voltage is 250VAC. It can directly drive industrial loads such as solenoid valves and contactors without the need for intermediate relays.

3. Supports RS-485 twisted pair serial communication, with a communication distance of up to 1000m, and can be extended to fiber optic or wireless communication methods in long-distance scenarios.

4. Seamless compatibility with ABB Beli DCS control system, can directly connect to the original control architecture, and achieve efficient data exchange with the lower level PLC.

5. Electrical isolation design is adopted between channels, with an isolation voltage of ≥ 1500VAC, effectively resisting electromagnetic interference in industrial sites and ensuring signal stability.

6. Compatible with mainstream industrial protocols such as Modbus RTU and Profibus DP, flexible docking with various industrial control upper computers and controllers, with strong universality.

7. The working temperature ranges from -20 ℃ to 60 ℃, with a relative humidity of 5% -95% (non condensing), and can withstand harsh working conditions such as high and low temperatures, humidity, etc.

8. Built in contact status feedback function, which can monitor the on/off status of the output circuit in real time, accurately locate load faults, and ensure more efficient operation and maintenance.

9. Equipped with dual color LED indicator lights, it divides module operation status and channel output status, visualizes feedback on work status, and facilitates troubleshooting.

10. Adopting standardized DIN rail installation, the industrial grade flame-retardant shell has a protection level of IP20, is dust-proof and oil proof, and is suitable for installation inside control cabinets.

11. Supports level signal and pulse signal output modes, which can meet diverse industrial control needs such as continuous control and intermittent triggering.

12. Built in overcurrent and short-circuit protection circuits, automatically cutting off fault channels to avoid damage to modules and front-end actuators, with excellent safety.

13. Support remote parameter configuration and status monitoring, without the need for on-site module disassembly, reducing maintenance costs and workload in industrial sites.

14. Adopting detachable plug-in terminal blocks, the wiring is firm and vibration resistant, supporting pre wiring operations, greatly improving on-site installation efficiency.

15. Complies with IEC industrial safety standards and CE certification, rigorously controls product reliability, and is suitable for various industry scenarios such as petrochemicals, power, metallurgy, etc.

IMDSO01 Product imag
