NAMM03 Network Simulation Main Module

NAMM03 Network Simulation Main Module

Product Details Introduction

NAMM03 Network Simulation Main Module Product Features (15)

1. ABB Bailey original network simulation main module, designed to build core simulation control nodes for Infi 90/Net 90 systems.

2. It combines analog signal processing and network collaborative control functions, suitable for industrial automation centralized monitoring scenarios.

3. Supports cascading expansion of multiple modules, can manage 16 subordinate modules in a coordinated manner, and build a distributed analog signal network.

4. Compatible with thermocouples, thermal resistors, and standard analog signals, suitable for multiple types of sensor access requirements.

5. 16 bit high-precision A/D conversion, with an input accuracy of ± 0.1% FS, ensuring the accuracy of analog signal acquisition.

6. Integrated industrial Ethernet interface, supporting Modbus TCP protocol to achieve high-speed data exchange across systems.

7. Built in dual filtering mechanism effectively suppresses electromagnetic interference and ensures stable signal transmission under complex working conditions.

8. 2500V AC photoelectric isolation is installed between the input, output, and power supply to block ground loop interference and enhance safety.

9. 24V DC wide voltage power supply, equipped with overvoltage, overcurrent and reverse connection protection, suitable for industrial standard power supply environment.

10. Equipped with main station level fault diagnosis function, it can monitor module linkage status in real time and trigger alarm mechanism.

11. Can withstand a wide temperature range of -40 ℃ to 70 ℃, suitable for 95% high humidity without condensation conditions, and has excellent environmental adaptability.

12. Modular and compact structure, supporting DIN rail installation, saving control cabinet space, and facilitating later maintenance.

13. The sampling rate can reach up to 50ms/channel and can be adjusted as needed to meet the requirements of high-speed response control.

14. Anti corrosion coating treatment on PCB board to resist industrial corrosive gases and extend the service life of modules.

15. Seamless integration with ABB DCS system, widely applicable to core industrial scenarios such as power, chemical, and metallurgical industries.

NAMM03 Product imag
