853-228778-004 Engine Control Module

853-228778-004 Engine Control Module

Product Details Introduction

eight

1. Precise control under all working conditions: 853-228778-004 real-time collects multi-sensor signals such as crankshaft position and intake temperature, dynamically optimizes fuel injection quantity and ignition timing, adapts to complex working conditions such as idle and rapid acceleration, and provides smoother power output.

2. Adaptation to high temperature extreme environments: Adopting firewall design and materials resistant to 260 ℃ high temperature, in compliance with EN2997 standard, it can resist the risk of engine compartment fire. The working temperature covers -40 ℃~+105 ℃, and is suitable for harsh scenarios such as aviation and heavy machinery.

3. Strengthened anti vibration structure: Equipped with a self-locking fine thread connection mechanism, it supports random vibration from 5Hz to 2000Hz (1g ²/Hz), and has passed the 3-axis 20g peak impact test, meeting the MIL-DTL-83723 military grade vibration requirements.

4. Efficient energy conservation and emission reduction: Through closed-loop control of air-fuel ratio and optimization of ignition advance angle, combustion efficiency is improved by more than 12%, and harmful gas emissions are reduced by 18%, meeting strict environmental regulations and low-carbon operation requirements.

5. Multiple safety protection system: Built in overvoltage (16V) and reverse voltage (-14V) protection, equipped with short-circuit protection and insulation design (insulation resistance ≥ 10M Ω), while supporting failure protection mode to maintain basic operation in case of failure.

6. Multi protocol collaborative communication: integrates 3 CAN buses and 2 LIN buses, supports K-line diagnosis, and can work in conjunction with the transmission control module (TCM) to achieve integrated control of the powertrain.

7. High reliability hardware architecture: Equipped with a 32-bit high-performance processor and ECC verification memory, and sealed with glue to enhance moisture and salt spray resistance (salt spray test up to 500h), MTBF exceeds 500K hours.

8. Functional safety compliance design: Compliant with ISO 26262 ASIL B level requirements, equipped with a dual core locking architecture and a comprehensive self diagnostic mechanism, real-time monitoring of circuit status and recording of fault codes for quick troubleshooting.

9. Wide voltage stable operation: The working voltage covers 9V~16V, supports 24V overvoltage protection and reverse polarity protection, is compatible with different power systems such as passenger cars and commercial vehicles, and has strong power supply stability.

10. Multi standard global compliance: Passed MIL-DTL-83723 military certification, KMVSS safety certification, and RoHS environmental certification, electromagnetic compatibility meets ISO/CISPR specifications, and adapts to entry requirements in various fields such as aviation and automotive.

853-228778-004 Product imag

853-228778-004 ontroller Module
