832-210822-001 Controller Module

832-210822-001 Controller Module

Product Details Introduction

832-210822-001 Controller Module Core Product Features

1. High precision signal acquisition and control: 832-210822-001 supports 12 channels of optoelectronic isolated digital input (12V~24V) and 8 channels of relay output, with an input accuracy of ± 0.15% FSO and an output current of 10A, suitable for multiple types of sensors and actuators.

2. Flexible adaptation of dual-mode communication: Integrated RS232 serial port and wireless WIFI dual communication interface, the serial port is used for program download and communication with the upper computer, and WIFI supports wireless control of mobile terminals to meet local and remote operation needs.

3. Triple working mode switching: supports three modes: independent automatic control, serial port monitoring, and wireless WIFI monitoring. Logic programs can be written in KEIL C language to adapt to distributed control systems and remote IO scenarios.

4. Wide temperature range stable operation: The working temperature range covers -54 ℃~+120 ℃, with a temperature compensation accuracy of ± 0.005% FS/℃, suitable for extreme high and low temperature environments in industrial sites, and a protection level of IP54.

5. Strengthen safety protection design: Built in lightning protection and anti electromagnetic interference circuits, equipped with triple protection of overcurrent, overtemperature, and short circuit, relay output integrated with high-frequency filtering, in compliance with GB/T 37933 industrial control safety standards.

6. High reliability hardware architecture: using stainless steel welding structure and high stability components, insulation resistance ≥ 1000M Ω @ 50Vdc, MTBF over 300K hours, suitable for high vibration and multi dust industrial scenarios.

7. Multi standard signal compatibility: Compatible with multiple types of inputs such as thermocouples (K/J/E/N type), with a range covering -129 ℃~1371 ℃, supporting 0.1 ℃ resolution display, and suitable for monitoring multiple parameters such as temperature and pressure.

8. Convenient remote operation and maintenance: Supports SCPI instruction set and MODBUS protocol, allowing real-time reading of device status and configuration parameters through the upper computer. Fault logs are retained for at least 6 months for easy traceability and troubleshooting.

9. Multi compliance certification guarantee: Complies with CE, UL, and ROHS certifications, meets GB/T 18336 industrial control product safety standards, passes EMC electromagnetic compatibility certification, and adapts to global industrial scene access requirements.

10. Compact and flexible installation: With dimensions of only 148mm × 105.5mm × 28mm, it supports both rail and onboard dual installation methods, paired with status indicator lights and graphical interfaces, making deployment and maintenance efficient and convenient.

832-210822-001 Product imag

832-210822-001 ontroller Module
