3152419-206 RF Generator

3152419-206 RF Generator

Product Details Introduction

3152419-206 RF Generator Core Product Features

1. Wide band precise output: The working frequency of 3152419-206 covers 150kHz and 3GHz, with a frequency resolution of 10Hz. It supports wide range power adjustment of -127dBm and 13dBm, and is suitable for multi scene RF signal requirements.

2. Intelligent impedance matching system: Built in automatic impedance matching algorithm, can dynamically compensate for 50 Ω standard load impedance deviation, voltage standing wave ratio (VSWR)<1.2, maximizing power transmission efficiency.

3. Multi mode modulation function: Supports AM/FM/PM analog modulation and digital modulation such as ASK/FSK/PSK, compatible with continuous wave and trigger modes, meeting differentiated scenarios such as RF testing and communication verification.

4. Triple remote control interface: integrates USB, LAN (MODBUS-TCP), and RS485 (MODBUS-RTU) interfaces, supports SCPI instruction set, and can seamlessly integrate into automated testing systems.

5. High frequency stable operation design: Adopting high stability crystal oscillator and phase-locked loop technology, the frequency stability reaches ± 0.1ppm/℃, the power stability is better than 0.88% RMS for 3 hours, and the signal output consistency is strong.

6. Comprehensive safety protection: Built in over power, over temperature, and standing wave protection functions, automatically derating when the reflected power exceeds the standard or the temperature is abnormal, in compliance with EN 60215 electrical safety standards.

7. Wide temperature range adaptation: Operating temperature range of -20 ℃~+65 ℃, supporting operation at an altitude of 2000 meters, suitable for complex environments in laboratories and industrial sites, with a protection level of IP54.

8. High electromagnetic compatibility performance: Passed EN 55032 B-level electromagnetic compatibility certification, with low radiation and conducted interference, avoiding signal interference to sensitive electronic devices in the surrounding area.

9. Multi standard compliance certification: Complies with CE, UL, and ROHS certification requirements, meets the spectrum usage specifications of the EU RED directive, and adapts to major global market access needs.

10. Compact integrated design: Adopting modular packaging technology, it is compact in size and supports rail mounted installation. With a graphical user interface, deployment and operation are convenient and efficient.

3152419-206 Product imag
