A68DAI-S1 Programmable Controller

A68DAI-S1 Programmable Controller

Product Details Introduction

Core positioning

Mitsubishi MELSEC-A series exclusive analog input module, the core function is to collect 4-20mA/0-10V signals from industrial field sensors (temperature/pressure/flow, etc.), convert them into digital signals recognizable by PLC, and adapt to the automation control scenarios of A series PLC hosts.

Core Highlights

8-channel differential input, full range measurement accuracy ± 0.1%, precise data acquisition; 10ms/channel sampling with filtering function, strong anti-interference ability, suitable for complex industrial environments; 34 pin plug-in design, powered by DC5V (0.2A), easy to install and maintain.

Quick overview of key parameters

Physical specifications: 130 × 34.5 × 93.6mm, weight 0.17kg

Interface characteristics: Voltage type input impedance ≥ 1M Ω, current type 250 Ω

Environmental requirements: 0-55 ℃ working temperature, ≤ 90% humidity without condensation

Adaptation and Application

Compatible with A series PLCs such as A1SX41/A2ASCPU

Supporting components: Alternative model A68DAI, terminal block A6TBXY36, calibration tool A6CAL

Typical scenarios: Automated production lines, process control, and data collection from various sensors

A68DAI-S1 Product imag

A68DAI-S1ontroller Module
