LXM32MD18M2 servo controller

LXM32MD18M2 servo controller

Product Details Introduction

Basic information: LXM32MD18M2 belongs to the 200-240V single-phase power supply type, with a suitable motor power of 1.6kW.

Performance Characteristics

Strong overload capacity: It can provide peak current up to 4 times the rated current, expanding the driving range.

High power density: The driver is compact in size and can achieve high efficiency in a small space.

Excellent control performance: With high bandwidth, it can achieve better speed stability and faster acceleration. It also reduces vibration through automatic parameter calculation and is equipped with a speed observer and external band stop filter, improving control quality.

flexibility

Rich interfaces: comes standard with logical or analog inputs and outputs, which can be flexibly configured to adapt to different applications. It also has a control interface, supports pulse sequence control, integrates CANopen/CANmotion ports, and can be connected to mainstream communication networks and buses such as DeviceNet, Ethernet/IP, PROFIBUS DP V1, EtherCAT, etc. through various communication cards.

Diverse operating modes: Supports multiple control modes to meet the needs of different motor types and operating scenarios.

Safety: Integrated with the "Safe Torque Stop" (STO) function, it complies with the SIL3 level of IEC/EN 61508 and the IEC/EN 61800-1 electric drive system standard, which can prevent accidental restart of servo motors. It can also be equipped with an additional eSM module to further enhance safety functions.

Application areas: Suitable for various industrial fields such as printing, packaging, textile, and handling, it can be used for common application scenarios such as cutting, fixed length cutting, winding, conveying, and palletizing.

Certification standards: Compliant with international standards IEC/EN 61800-5-1 and IEC/EN 61800-3, and certified by UL and CSA. Its development also complies with RoHS directive requirements.

LXM32MD18M2 Product imag
