MR-J3-100BS4 servo drive

MR-J3-100BS4 servo drive

Product Details Introduction

MR-J3-100BS4 is a Mitsubishi original MELSERVO-J3 series servo drive, with stable core performance and compliance with industrial high-precision drive standards.

Suitable for scenarios such as CNC machine tools, industrial robots, and material conveying systems, with strong universality and covering the automation needs of multiple industries.

Rated output power of 1.0kW, output current of 2.8A, strong and stable power drive, suitable for medium power servo motors.

Integrated STO safety function (IEC/EN 61800-5-2 standard) can achieve safe torque shutdown without the need for additional electromagnetic contactors.

Support SSCNET III high-speed fiber optic communication, with a communication cycle as low as 0.44ms, fast signal transmission, and strong anti-interference ability.

MR-J3-100BS4 adopts a fully closed-loop control system that receives feedback from the load side encoder to improve positioning accuracy and stability.

The power specification is three-phase AC400V, with a wide voltage adaptability range, which can cope with small voltage fluctuations in industrial sites.

Built in dynamic braking function, quick start stop response, effectively improving equipment operation efficiency and safety guarantee.

The protection level reaches IP20, suitable for installation inside control cabinets, dustproof and foreign object intrusion prevention, ensuring the safety of electrical components.

Compact design with a width of only 60mm and a weight of 2.0kg, saving installation space for control cabinets and adapting to multi axis layouts.

The working temperature range is from 0 ° C to 55 ° C, suitable for industrial conventional temperature control environment, and the operational stability is not affected by temperature.

MR-J3-100BS4 is compatible with Mitsubishi Q series motion controllers, with convenient integration and docking, without the need for additional adaptation modules.

Support one click gain adjustment, automatically optimize mechanical resonance and seismic control, and reduce debugging difficulty.

Original genuine product guarantee, in compliance with multiple international certifications such as CE, UL/UL, EAC, etc., with strong compliance in use.

Equipped with an intuitive monitoring interface, supporting parameter configuration and real-time diagnosis, and convenient and efficient maintenance operations.

MR-J3-100BS4 is compatible with MR-J3-B series installation and wiring, and can be directly replaced and upgraded to reduce renovation costs.

Excellent insulation performance, high electrical safety, in compliance with industrial electrical standards, and operates without any safety hazards.

Provide 12 months of original factory warranty, sufficient stock supply, efficient logistics and distribution to meet maintenance and replacement needs

MR-J3-100BS4  Product imag
