SRM50-HWA0-K22 servo motor

SRM50-HWA0-K22 servo motor

Product Details Introduction

SRM50-HWA0-K22 generates 1024 sine and cosine signals per circle, resulting in 32768 absolute positions after subdivision, with a positioning accuracy of ± 52 ″

Supports 4096 cycles of multi cycle measurement, with a total of 134217728 steps, meeting the requirements of long-distance precision control

Equipped with HIPERFACE ®  Interface, capable of synchronously monitoring speed, position, and direction change, with precise and error free signal transmission

The working speed of SRM50-HWA0-K22 can reach 6000rpm, with an angular acceleration of ≤ 200000 rad/s ² and agile high-speed response

Protection level up to IP65, dustproof, waterproof, splash proof, suitable for humid and dusty industrial site environments

The power supply voltage is 7-12VDC, and it is recommended to supply 8VDC. The current consumption is only 80mA, and the low power consumption and energy saving are outstanding

Adopting a 10mm solid shaft design, with a radial load of 40N and an axial load of 20N, the mechanical load-bearing capacity is strong

SRM50-HWA0-K22 operates within a temperature range of -30~+85 ℃, with a wide temperature range suitable for complex working conditions in multiple regions

Equipped with electronic nameplate function, supporting encoder and motor model recognition, parameter management is more convenient

The impact resistance reaches 100g, the vibration resistance is 20g (10-2000Hz), and the operation is stable in complex environments

Equipped with M23 12 pin radial male connector, reliable wiring, supports long-distance cable transmission

SRM50-HWA0-K22 has built-in 1792Byte storage space, which can store motor information and custom parameters

Compliant with SIL2/PLd safety certification and RoHS standards, compliant for global industrial applications

The moment of inertia is only 25gcm ², the operating torque is 1Ncm, there is no impact during start stop, and the motor components are protected

Flange installation design, weight ≤ 0.2kg, compact volume, saving equipment installation space

SRM50-HWA0-K22 Product imag
